Aparat anestezie inhalatorie animale mari DRE VETERINARY TITAN LARGE ANIMAL

“The DRE Titan is extremely effective, easy to use and maintain, and very dependable. I am so pleased with the Titan and the DRE service team that I have ordered two more Titans for the Ruffian Equine Medical Center at Belmont Park.�

Patricia M. Hogan, VMD, ACVS – Director of Surgery
Ruffian Equine Medical Center, Belmont Park



The DRE Titan Large Animal Anesthesia Machine is a complete anesthesia support system. The Titan is designed for use with Equine, Bovine, Zoology, and other large animal anesthesia techniques. The system can be used for spontaneous breathing or the user may utilize the popular reconditioned Drager AVE ventilator which is an electronically controlled, time cycled driven anesthesia ventilator capable of delivering from one-half (½) to 15 liters of tidal volume at 1 to 99 breaths per minute and I:E ratios from 1 to 2 to 1 to 8.

Features:

• For use with large animals
• 5-15 liters of tidal volume available
• Ventilator is time cycled and electronically controlled
• Frequency control variable from zero to ninety-nine breaths per minute in one BPM increments
• Inspiratory flow controlled through operator adjustable regulator
• Touch control tidal volume adjustment
• Vapor exlusion system protects from both vaporizers delivering agent. One is in use, while the other shuts off.
• Top of machine acts as a storage shelf; particularly good for placing a monitor on

Optional:

• Foal absorber
• Extended inspiratory and expiratory ratios
• Large animal sized endotracheal tubes available upon request

Includes

• CO2 absorber, bellows, refurbished drager ventilator, 2 circuits, and breathing circuits. Does not include the foal absorber.

Warranty

• 3 Year Warranty

TECHNICAL SPECIFICATIONS:

• Electrical Specs: 120 VAC 50/60 Hz.
• Dimensions:
  • Height - 53"
  • Base Width - 31"
  • Base Depth - 31"
• Ventilator Specs:
  • On/Off Switch: Provides AC power to AVE Vent.
  • Tidal Volume: Motor driven adjustable tidal volume through use of a momentary rocker switch. 5-15 liters of tidal volume available via descending bellows being drive gas compressed.
  • Ventilator: Time cycled, electrically controlled, pneumatic powered.
  • Frequency Control: Variable from 0 to 99 breaths per minute in one BPM increments.
  • Inspiratory / Expiration: I:E ration available: 1:1, 1:1.5, 1:2, 1:2.5, 1:3, 1:3.5, 1:4, 1:4.5
  • Inspiratory Flow: Controlled through operator adjustable regulator (Low, Med, High).
• Absorber Specs:
  • Circuit pressure gauge: -20cm/H20 to 80cm/H2O range
  • APL Value: Adjustable pressure limit valve allows control from completely closed to fully open. Fully open 3 cm/H2O lift.
  • Insp./Exp. Ports: Inspiratory and expiratory flow controlled through visible check valves.
• Options:
  • I:E ratio upgrade: Allows for delivery of: 1:2, 1:2.5, 1:3, 1:3.5, 1:4, 1:4.5, 1:6, 1:8 ratios.
  • Foal absorber: Separate absorber reduces down time while switching to a separate machine for foal or small animal anesthesia.  2000cc capacity with 22mm ports, pressure gauge, APL valve
  • Open air scavenging system: For use with suction (vacuum) waste gas disposal systems.
  • E-cylinder mounting: Provides a safe back up supply of oxygen in the event of a main O2 supply failure.
  • Isoflurane vaporizer: Temperature compensated wick style vaporizer with range of 0% - 5%.
  • Sevoflurane vaporizer: Temperature compensated wick style vaporizer with range of 0% - 7%.
