Aparat anestezie inhalatorie DRE VETERINARY COMPACT (compatibilitate MRI)

Product Features:

When space and reliability are your most important concerns, the Compact is the logical choice.

• 0.1 to 0.4 oxygen flowmeter with rotary float.
• Rotary float and large scale for easy readability.
• Recessed flush valve to prevent accidental activation.
• Quick-connect fresh gas outlet for easy and secure switching between breathing circuits.
• SELECTATECâ„¢ compatibility manifold for easy and quick installation of vaporizer.
• Mobile five wheel spider base.
• 1500 ml CO2 absorber designed for easy and fast replenishing of sodalime. Condensation trap to prevent water build-up in sodalime. Easy and efficient gas sealing.
• Patient circuit with 2 and 3-liter bags.
• New momentary closed feature incorporated into the pop-off valve.

Available Options:

• Anesthesia vaporizer (Sevoflurane,Isoflurane, Halothane)
• Bain circuit adaptor
• Scavenger interface:
  • For fan or blowing assemblies
  • For central vacuum system
• E-tank holder
  •  Single and dual available
• Circuit Alarm
• MRI compatibility (see below)
• Wall-mount unit available

Additonal Model: MRI-Compatible Compact Anesthesia Machine (pictured above in sub images)

• Constructed with non-ferrous materials
• All of the same features to that of the regular Compact Anesthesia Machine mentioned above
• Available with the Penlon Nuffield Anesthesia Ventilator as an option
  • MRI-compatible, pneumatically-driven, time-cycled ventilator
  • Pre-set volume and flow rate for small or large animals
  • Powered by medical air or oxygen at 340 kPa - 410 kPa
  • Dimensions:
    • Length: 68.58 cm | 27"
    • Width: 66.04 cm | 26"
    • Height: 138.43 cm | 54.50"
    • Weight: 12.27 kg | 27 lbs.
  • Shipping Box Dimensions:
    • Length: 68.58 cm | 27"
    • Width: 66.04 cm | 26"
    • Height: 45.72 cm | 18"
    • Weight: 19.54 kg | 43 lbs.
  • Materials:
    • Brass
    • Aluminum
    • Plastic
    • UHMW
