Aparat anestezie inhalatorie DRE VETERINARY OPTIMAX

Product Features:

The DRE Moduflex Optimax anesthesia machine is a working station that combines ingenuity, sophistication and practical common sense.  The Optimax is a flexible high end machine that holds 2 vaporizers.  This machine is typically used (but not limited to) by Universities, Teaching & Research Facilities, and specialty veterinary surgeons.

• Rebreathing machine
• 0.1 to 5 lpm flowmeter.
• Rotary float and large scale for easy readability
• Recessed flush valve to prevent accidental activation
• Quick-connect fresh gas outlet for easy and secure switching between breathing circuits
• SELECTATECâ„¢ compatiblity manifold for easy and quick installation of two vaporizers
• Vaporizer interlock compatibility
• Drawer assembly pack
• Coaxial or conventional CO2 absorber
• Convenient instrument and upper monitor shelves
• New momentary closed feature incorporated into our pop-off valve
• Circuit and line pressure gauges.

Available Options:

• Anesthesia vaporizer (Halothane, Isoflurane, Sevoflurane)
• Up to three flowmeters can be installed
  • O2 - AIR - N2O - CO2
• E-tank holder - please specify at time of order
• Bain circuit adaptor
• Scavenger interface:
  • For fan or blowing assemblies
  • For central vacuum system
• Wall-mount unit available

• Dimensions:
  • Length: 64.77 cm | 25.50"
  • Width: 49.53 cm | 19.50"
  • Height: 137.16 cm | 54"
  • Weight: 34.09 kg | 75 lbs.
• Shipping Box Dimensions:
  • Length: 69.85 cm | 27.50"
  • Width: 67.31 cm | 26.50"
  • Height: 127.54 cm | 51"
  • Weight: 57.27 kg | 115 lbs
• Materials:
  • Brass
  • Aluminum
  • Acetal
  • Painted Steel
  • UHMW
