Aparat radiologie dentara veterinara DRE VETERENIRY DENTAL X-Ray UNIT

The Dental X-Ray Unit - aparat radiologie dentara veterinara

Features:

• Long reach double positioning arm
  • For wall mount version or portable version(s)
  • Easily moves and folds compactly when not in use.
  • Drift free stability
• Standard, short or long extension arm
  • For wall mount version
  • Designed to fit your personal requirements
  • Standard extension arm provides a total inside reach of 71 1/8" | 180.6 cm
  • Short extension arm provides a total inside reach of 53 3/8" | 135.6 cm
  • Long extension arm provides a total inside reach of 75" | 190.5 cm
• 70 KVp Tubehead
• The 70 KVp-8mA Tubehead with a small focal spot, low energy filter and beam limiting device asures outstanding sharpness and maximum details in intra-oral radiography.
• An angle indicator on both sides of the unit allows for positioning to be made easier.
• Protection: Lead shields and critical components are oversized to provide more years of safe and trouble free operation.
• Shown seperately on sub-image #3
• Intraoral Veterinary Dental X-Ray Units
• A powerful microprocessor will automatically choose the exposure time, according to the type and position of the tooth, patient size, film or digital sensor; with automatic compensation for the main voltage variations, or manual override if required.
• Efficiently obtain the optimized technical factors that will provide constant radiographic density, with less radiation exposure.
• Full protection against x-ray tube overheating; the microprocessor will set the minimum cooling period between exposures - extending the tubehead life.
• Hand Held Digital Exposure Timer
• Hand-held (small size), 3 digit remote controller with a 1/100 of a second resolution, fully compatible with the fastest film or a filmless digital imaging system.
• Fully compatible with the fastest film or a filmless digital imaging system.
• 9 factory pre-set memories, patient size, film or digital sensor, or manual override if required.
• Optional remote timer configuration, if the controller is to be located outside the operatory.
• Shown seperately on sub-image #4

DRE Dental X-Ray Unit is a wall mounted or mobile system

• Wall mounted in the x-ray room or directly in the treatment room, even for side-by-side operatory stations.
• Mobile stand, to reach sepearte operatory stations on a sturdy and stable rolling stand.



  Portable stand.

  Specifications:

  Rated Line Voltage:  120% ± 10% (109-132 V.a.c). 50/60 Hz

  Power Consumption:  1050 KW max @ 132 V.a.c

  Rated Tube Current:  8 mA ± 15% @ 120 V.a.c

  Exposure Time Range:  0.03 to 3.00 s, in steps of 0.01 s. Plus 9 pre-set exposure times, with automatic main voltage compensation.  A pre-heating time of 0.15 s. for loading the x-ray tube is not shown on the display.

  Minimum Focal Spot To Skin Distance:  200 mm. (8")

  Radiation Leakage @ 1 m.:  Less than 50 mR/h

  Focal Spot: 0.8 x 0.8 mm.

  Total Filtration:  2 mm. Al eq.

  Net Weight:  Mod. WM (Wall Mount): 28 Kg | Mod. MM (Mobile Stand):  40 Kg

  Shipping Weight:  Mod. WM: 33 Kg | Mod. MM:  48 Kg

  Shipping Dimensions:  Mod. WM: 1 box, 131 x 52 x 26 cm | MM: 2 boxes, 111 x 34 x 19 cm, and 86 x 34 x 33 cm
