   DRE Veterinary Maxx Luxx II Operating Room Lights The DRE Maxx Luxx II System is a
modular system designed to evolve and expand with the introduction of
new models. With the original MAXX LUXX II a standard of excellence was
set. The MAXX LUXX II offers advanced features for demanding surgical
environments at a cost far below comparable lights on the market. Image of 23" head
Features and Benefits Include:
-
Four brightness settings,
allowing you to adjust its output of cool, color-corrected light to fit
your needs. Outputs of 100%, 85%, 70%, and 50%
-
Adjustable pattern sizes
-
Electronic touch controls for on/off and dimming
-
Smooth, flexible and extensive suspension arms for maximum coverage
-
A reserve bulb that automatically switches over in the event of a primary bulb failure
-
Excellent shadow control
Orbital MountingAnother
significant milestone was the introduction of the Orbital style ceiling
mountings, which opened whole new avenues of articulation and freedom
of movement.
Satelite & Video & Mounting OptionsThe
most recent innovation is the introduction of the MAXX LUXX II 18"
Satellite Surgery Head and the PCAM Video Unit. With the addition of
these fine new models, the parameters of lighting and video in the
surgery room have increased dramatically. The availability of single,
dual, or trio mountings make virtually any combination of these models
possible.
MAXX LUXX II - 23" Surgery Light Head
The
foundation of surgery room lighting - the 23" MAXX LUXX II with it's
20" (508mm) diameter, multi-faceted reflector and long list of standard
features, it provides the core of illumination for the operating room
environment.
High output, excellent color
temperature, pattern adjustment, four stage dimming, auto buld reserve,
extensive arm articulation and single, dual, or trio mounting options
make the MAXX LUXX II a great choice for the discriminating surgeon.
MAXX LUXX II - 18" Satelite Surgery Light Head
The
new 18" head provides the perfect compliment to the 23" with an
excellent balance of output, color temperature and more features than
typically found in many larger surgery lights.
The 18" model can be ordered solo
or easily combined with the 23" and / or the PCAM Video Camera Unit to
create an entirely new dimension in mult-purpose surgical lighting.
PCAM Video Unit
This
unit breaks the barrier of cost in quality surgery light applications.
For the first time, a full surgery lighting system is offered with a
video camera at a lower cost than ever before for such extensive high
end equipment.
The PCAM features a 27x optical
zoom and 10x digital zoom with auto focus, manual focus, and the option
of a single-input controller or one that accomodates up to 8 video
units. Comes equipped with an S-video for one input. The MAXX LUXX II
System can utilize the video camera for monitoring, taping, educational
uses and more. The PCAM can be combine with the other MAXX LUXX II
units for a variety usefull of combinations.
3 Ceiling Mounting Options Available:
Single Mount
Can
consist of either a 23" or 18" head with continuous rotation of all
critical pivot points, along with the extensive arm coverage.
Dual Mount
Allows
for the pairing of the 23" lights and / or the 18" satelite lights, or
the combination of one of each. You can also combine one of the light
heads with the video camera.
Trio Mount
Any
combination of the 23" head, 18" head, or PCAM can be used to create a
completely dynamic lighting environment using three different mobile
mounting points. | Light Intensity at 39" (1 meter) |
102,000 lux (9,500 ft-candles) |
| Light Field Diameter (adjustable) |
6.5"-9.0" Dia. |
| Depth of Illumination |
48" |
| Color Temperature |
4000 K |
| Color Rendering Index |
90 CRI |
| Light Dimming Settings ( 7 discrete) |
50% - 100% |
| Light Source (primary) |
150 W Tungsten Halogen Bulb |
| Light Source (secondary, back-up) |
150 W Tungsten Halogen Bulb |
| Rated Bulb Life (primary and secondary) |
1000 hours |
| Reflector |
20" Facetted Alzak Aluminum |
| Filter Type |
I/R Filter Glass |
| Sterilizable Handle |
Standard |
| Input Voltage Range |
100-125 Vac 50/60 Hz |
|
220-240 Vac 50/60 Hz |
| Lamp Voltage |
23-25 Vac |
| Light Head Dimensions |
23.0" Dia. X 14.0" High |
| Arm Length (Maximum Length) |
74" from center mount to light. |
| Lamp Head Rotation |
Continuous |
| Vertical Arm Movement |
+20,-70 degrees |
| Ceiling Mount/Extension Arm |
540 degrees |
| Minumum Mounting Height |
96" (2438mm) |
| Maximum Mounting Height |
156" (3962mm) |
| Yoke/Light Head Joint |
+/-150 degrees |
| Weights (based on 8 ft. ceiling height): |
|
| Single Ceiling Mount |
25 pounds |
| Double Ceiling Mount |
32 pounds |
| Arm Assembly |
15 pounds |
| Light Head Assembly |
17.5 pounds |
|
|
MAXX LUXX II 18" - Satelite Head SPECIFICATIONS
-
6,700 ft candles (72,00 lux)
-
4000 degrees Kelvin color temperature.
-
6.5" (165mm) - 9" (229mm) adjustable diameter light pattern.
-
48" (1219) depth of field.
-
7 settings of electronic dimming with outputs ranging from 50% to 100%.
-
72" (1829mm) extended arm coverage.
-
Auto-switchover to reserve bulb in case of primary bulb failure.
-
Minimum mounting height 96" (2438mm)
-
Maximum mounting height 156" (3962mm)
-
16" (406mm) diameter multi-faceted reflector.
-
18" (470mm) diameter outer head diameter.
P-CAM Video Camera Specifications
- Type: 1/4"CCD
- Resolution: 537 (h) x 505(y) NTSC & 537 (h) x 597(y) PAL
- Integral Lens
- Optical Zoom - 27x; with digital zoom - 10x
- Focal length 39" (1 meter)
- Low Power Consumption
|
